Product Feature
◆ Touch fluid material: aluminum oxide ceramic, corrosion resistance, high temperature resistance,high pressure resistance, ultra-high wear resistance, applicable to a variety of special media.
◆ Serial communication protocol: support RS232/RS485 bus.
◆ Control protocol: ASCII code protocol, custom protocol, Modbus protocol, CAN protocol can be customized.
◆ Applicable occasions: flexible adaptation, suitable for rapid switching of the flowchannel, the internal flow channel residual and volume requirements of the higher occasions. Widely used in water quality analysis instruments, experimental analysis instruments, medical analysis instruments and other equipment.
Highlights
Spool structure: the spool adopts multi-directional adaptive plane fitting mode, whichcan effectively extend.the product life. (This structure has applied for(Utility Model Patent, Patent No. CN204852471U)
Power: The valve body rotation adopts NMB imported planetary gearbox motor as the power device, with high reliability.
Valve hole positioning: Adopt absolute position encoder positioning, which can effectively solve the problem.of not being able to accurately position the valve hole after the gearbox is worn out; And has the advantage of anti-pollution and anti-dust.
