Two-Position Switching Valve

Two-Position switching valve was designed with 6, 8, 10 ports of multiple fluid channels. This fast switching solenoid valve is programmable controlled via communication RS232/RS485/CAN by a maintenance-free stepper motor driving system, small layout make it very popular in laboratory bench-top devices or medical miniaturized systems. Runze is a professional switching valve manufacturer and supplier, we are able to offer various fluid control equipment. If you want to know more, please contact us now!

  • Two-Position Switching Valve
  • Two-Position Fast Switching Solenoid Valve for Sale
  • Runze Two-Position Switching Valve
  • Two-Position Switching Valve
  • Two-Position Fast Switching Solenoid Valve for Sale
  • Runze Two-Position Switching Valve
Send Mail
Share this product:

Video of Two-Position Switching Valve




Model Numbers of Two-Position Switching Valve


Two-Position Switching Valve


Flow Configuration of Two-Position Switching Valve


Two-Position Switching Valve


Specification of Two-Position Switching Valve


Orifice

1.2mm

Wetted material

PCTFE, Sapphire

Port configuration

6/8/10 port

Dead volume

5.4μL

Air pressure

0-0.5Mpa

Water pressure

0-0.6Mpa

Origin detection

Auto reset to initial position when powered on (optional and settable)

Liquid temperature

0-150℃

Connection

1/4-28UNF

Replaceable parts

Stator replaceable, sealed rotor irreplaceable

Transposition

Random start to any specific port

Driver

Non-optional

Valve drive

≤400ms

Max. torque

1.6N/m

Communication

RS232, RS485, CAN

Baud rate

RS232/RS485: 9600bps, 9200dps, 38400dps, 57600dps, 115200dps

CAN: 100Kbps, 200Kbps, 500Kbps, 1Mbps

Address & Parameter setup

Communication interface

Power supply

DC24V/1.0A

Max power

15W

Operating temperature

0℃-50℃

Operating humidity

<80% relative humidity, non-condensing

Dimension (L*W*H)

63.7*50.4*115.2mm

Net weight

0.437KG


Driver Port of Two-Position Switching Valve


Two-Position Switching Valve


Port

Description

+

DC24V positive

-

DC24V negative

TX

RS232 data input

RX

RS232 data output

GND

GND

H

CANH

L

CANL

A

RS485 A

B

RS485 B


Dimension (unit: mm)


Two-Position Switching Valve
